| 원래 장소: | 중국 |
| 브랜드 이름: | BRANDO |
| 인증: | CE |
| 모델 번호: | CA50T |
| 최소 주문 수량: | 1개 세트 |
|---|---|
| 가격: | negotiable |
| 포장 세부 사항: | 이너 박스, 통, 팔레트 |
| 배달 시간: | 4-7 일 |
| 지불 조건: | T/T, 서부 동맹, L/C, MoneyGram |
| 공급 능력: | 달 당 165000개 부분 |
| 항구 크기: | 2" | 코일 전압: | 24VDC, 220VAC |
|---|---|---|---|
| 작업 압력 범위: | 0.3 0.8MPa에 | 실을 꿴 맥박 제트기 벨브: | CA15T, CA20T, CA25T, CA35T, CA45T, CA50T, CA62T, CA76T |
| 드레서 견과 맥박 제트기 벨브: | CA25DD, RCA25DD, CA45DD | 침수 맥박 제트기 벨브: | CA50MM, CA62MM, CA76MM, CA89MM |
| 플랜지가 붙은 맥박 제트기 벨브: | CAC25FS, CAC45FS | 먼 안내하는 맥박 제트기 벨브: | RCA25DD, RCA20T, RCA45T, RCA50T, RCA62T |
| 애플리케이션: | 카트리지 필터, 봉투 필터, 세라믹 필터, 소결 금속 섬유 필터 | ||
| 강조하다: | 2 인치 펄스 제트 밸브,고옌 펄스 제트 밸브,고옌 흡진장치 밸브 |
||
2 Inch CA50T010-300 CA50T010-305 Goyen Type Pulse Jet Valve
Description:
This series of pulse jet valves includes models with threaded connections from 3/4'' to 3''. These valves are particular used for reverse pulse-jet filter cleaning of filter bags, cartridges, envelope filters, ceramic filters and sintered metal fibre filters.
They have an inlet port at 90° to the outlet port.
The pulse jet valves differ in types with an integrated pilot valve or with external pneumatic control.
The special design ensures extremely fast opening, high flow and easy installation.
Optionally, we also offer versions with ATEX certified pilot valves.
A well thought-out structure and a fast delivery time for spare parts such as diaphragms, springs and coils enable simple maintenances.
Technical data of Right Angle Pulse Jet Valves:
|
Model No
|
CA15T
|
CA20T
|
CA25T
|
CA35T
|
CA45T
|
CA50T
|
CA62T
|
CA76T
|
|
Nonimal size
|
φ15
|
φ20
|
φ25
|
φ35
|
φ45
|
φ50
|
φ62
|
φ76
|
|
Port Size
|
G1/2''
|
G3/4''
|
G1''
|
G1 1/4''
|
G1 1/2''
|
G2''
|
G2 1/2''
|
G3''
|
|
Working pressure
|
0.3 to 0.8MPa
|
|||||||
|
Temp. range
|
-5℃ to 55℃
|
|||||||
|
Relative humidity
|
≤85%
|
|||||||
|
Working
medium
|
Compressed clean air
|
|||||||
|
Voltage
|
24VDC, 220VAC
|
|||||||
Dimension of CA50T Goyen Type Pulse Jet Valve:
Video of CA50T Goyen Type Pulse Jet Valve:
Detail images of Goyen Type Pulse Jet Valves:
More Goyen Type Pulse Valve For You to Choose:
Threaded Type Immersion Type Dresser Nut Type Flanged Type
RCA Series Solenoid Coil Armature Assembly Pulse Controller
Installation:
1. Prepare supply and blowtube pipes to suit valve specification. Avoid installing valves underneath the tank.
2. Ensure tank and pipes are free from dirt, rust or other particulate.
3. Ensure supply air is clean and dry.
4. Mount valves to inlet pipes and blowtube to valves, ensuring no excess thread sealant can enter the valve itself.
5. Make electrical connections to solenoid or connect RCA pilot port to pilot valve (RCA valves only).
6. Apply moderate pressure to system and check for installation leaks.
7. Fully pressurise system.
8. Test fire and listen for proper actuation and crisp pulse noise.
