| 원래 장소: | 중국 |
| 브랜드 이름: | BRANDO |
| 인증: | CE |
| 모델 번호: | CA76T |
| 최소 주문 수량: | 1개 세트 |
|---|---|
| 가격: | negotiable |
| 포장 세부 사항: | 이너 박스, 통, 팔레트 |
| 배달 시간: | 4-7 일 |
| 지불 조건: | T/T, 서부 동맹, L/C, MoneyGram |
| 공급 능력: | 달 당 165000개 부분 |
| 항구 크기: | 3" | 코일 전압: | 24VDC, 220VAC |
|---|---|---|---|
| 작업 압력 범위: | 0.3 0.8MPa에 | 실을 꿴 맥박 제트기 벨브: | CA15T, CA20T, CA25T, CA35T, CA45T, CA50T, CA62T, CA76T |
| 드레서 견과 맥박 제트기 벨브: | CA25DD, RCA25DD, CA45DD | 침수 맥박 제트기 벨브: | CA50MM, CA62MM, CA76MM, CA89MM |
| 플랜지가 붙은 맥박 제트기 벨브: | CAC25FS, CAC45FS | 먼 안내하는 맥박 제트기 벨브: | RCA25DD, RCA20T, RCA45T, RCA50T, RCA62T |
| 애플리케이션: | 카트리지 필터, 봉투 필터, 세라믹 필터, 소결 금속 섬유 필터 | ||
| 강조하다: | CA76T001 Pulse Jet Valve,Goyen Pulse Jet Valve,Dust Collector Pulsing Valve |
||
Goyen Type Pulse Jet Valve CA76T001 CA76T001-331 CA76T001-301
This is CA76T Goyen Type Right Angle Pulse Jet Valve; Reference No: CA76T000, CA76T001, CA76T010, CA76T000-300, CA76T001-300, CA76T010-300, CA76T000-305, CA76T001-305, CA76T010-305, CA76T000-331, CA76T001-331, CA76T010-331. Threaded port connection; NBR diaphragm; 24V DC, 220V AC (50/60Hz) voltages for you to choose; other voltages can be customized.
Description:
This series of pulse jet valves includes models with threaded connections from 3/4'' to 3''. These valves are particular used for reverse pulse-jet filter cleaning of filter bags, cartridges, envelope filters, ceramic filters and sintered metal fibre filters.
They have an inlet port at 90° to the outlet port.
The pulse jet valves differ in types with an integrated pilot valve or with external pneumatic control.
The special design ensures extremely fast opening, high flow and easy installation.
Optionally, we also offer versions with ATEX certified pilot valves.
A well thought-out structure and a fast delivery time for spare parts such as diaphragms, springs and coils enable simple maintenances.
Technical data of Right Angle Pulse Jet Valves:
|
Model No
|
CA15T
|
CA20T
|
CA25T
|
CA35T
|
CA45T
|
CA50T
|
CA62T
|
CA76T
|
|
Nonimal size
|
φ15
|
φ20
|
φ25
|
φ35
|
φ45
|
φ50
|
φ62
|
φ76
|
|
Port Size
|
G1/2''
|
G3/4''
|
G1''
|
G1 1/4''
|
G1 1/2''
|
G2''
|
G2 1/2''
|
G3''
|
|
Working pressure
|
0.3 to 0.8MPa
|
|||||||
|
Temp. range
|
-5℃ to 55℃
|
|||||||
|
Relative humidity
|
≤85%
|
|||||||
|
Working
medium
|
Compressed clean air
|
|||||||
|
Voltage
|
24VDC, 220VAC
|
|||||||
Dimension of CA76T Goyen Type Pulse Jet Valve:
Video of CA76T Goyen Type Pulse Jet Valve:
Detail images of Goyen Type Pulse Jet Valves:
More Goyen Type Pulse Valve For You to Choose:
Threaded Type Immersion Type Dresser Nut Type Flanged Type
RCA Series Solenoid Coil Armature Assembly Pulse Controller
