원래 장소: | 중국 |
브랜드 이름: | Brando |
인증: | CE |
모델 번호: | BB14542505 |
최소 주문 수량: | 1대 pc |
---|---|
포장 세부 사항: | 안 상자, 판지, 깔판 |
배달 시간: | 5-8 일로 일합니다 |
지불 조건: | L/C (신용장), 전신환, 웨스턴 유니온 |
공급 능력: | 한달에 100000PCS |
구멍 치수: | 14.5mm | 높이: | 42.5mm |
---|---|---|---|
폭: | 36.0mm | 전압: | AC220V, AC110V, DC24V, DC12V |
힘: | 28VA, 20W, 14W | 연결관: | DIN43650A |
절연제 종류: | H | 에나멜을 입힌 철사 물자: | 구리 |
적당한 밸브 시리즈: | 공기 압축기 자동차 배출 밸브 | ||
하이 라이트: | 113-030-0137 솔레노이드 밸브 Coil,113-030-0120 솔레노이드 밸브 코일,자동차 배출 밸브 0545 코일 |
0545 120VAC 113-030-0137 36VAC 113-030-0120 Solenoid Valve Coil
The coils are the interchangeable piece of nass magnet’s modular solenoid valve system. The coil assembles onto the armature and it is the device that when energized creates the magnetic force that lifts the plunger off of the valve seat. Coil range in width 36 mm.
Steps and methods for properly installing a solenoid valve coil:
1. Check if the solenoid valve and the selected parameters are the same, such as differential pressure, etc. If the error occurs, the solenoid valve coil will be burned out. Voltage fluctuations should be within the normal range and meet the rated voltage.
2. Before connecting the pipeline, flush the pipeline and remove the residual dirt in the pipeline. If there are residual stains, it will affect the normal use of the solenoid valve. To prevent this, a filter should be installed in the pipeline.
3. Install the solenoid valve coil of the solenoid valve vertically on the horizontal and ground pipes. If there is a special situation, it cannot be installed vertically. The appropriate solenoid valve should be ordered in advance, otherwise the solenoid valve will not work properly.
4. When installing, add a safety process and install a manual cutting valve to facilitate maintenance in case of failure.
5. Pay attention to the direction when installing, can not be reversed, installed in the direction indicated on the package, and can be reversed in some special cases such as vacuum.
6. If the water may be damaged by the medium, you must take appropriate protective measures or choose a solenoid valve with a waterproof hammer function.
7. The solenoid valve cannot be energized all the time, otherwise it will reduce its life. Note that normally open, normally closed solenoid valves cannot be used with care.
Dimension of BB14542505 Solenoid Valve Coil :
Technical Data:
Product Features:
1. Using high quality wire which has UL approved; 2. Using high quality permeablity magnetic material which contain low carbon;
3. Using high quality housing material like PA66, PBT, PPS, BMC and so on.
4. Insulation class can be B, F, H, N, C;
5. Protection class can be IP65, IP67 & IP69K;
6. We also offer special coils like ex-proof coils, water proof coils and so on.
7. If you have special requirement, pls feel free to contact us.
Focus on your demands, Offer you best solution:
√ Contact us if some points you have doubt
√ Contact us if somewhere need to change
√ Contact us if not the one you are looking for
√ Contact us if you are doing designing
Welcome to your any question and inquiry!
담당자: Brandon
전화 번호: +8613454729544
