Name: VF5120 SMC Type 5/2 Way Solenoid Pneumatic Valve 24V DC 220V AC
Brand: Brando
SKU: VF5120
Price: 3 USD
Availability: InStock
Rating: 4.8 (168 reviews)

홈 제품 소개 공압 솔레노이드 밸브

VF5120 SMC Type 5/2 Way Solenoid Pneumatic Valve 24V DC 220V AC

제품 상세 정보:

원래 장소:	중국
브랜드 이름:	Brando
인증:	CE
모델 번호:	VF5120

결제 및 배송 조건:

최소 주문 수량:	1 PC
가격:	$3 to $ 5 per pc
포장 세부 사항:	개별적 박스, 통, 팔레트
배달 시간:	4 내지 7 근무일
지불 조건:	L/C, T/T, PayPal, 서부 동맹, MoneyGram
공급 능력:	달 당 200000 PC

접촉

상세 제품 설명

벨브 유형:	5곳 길 2 위치	포트의 크기:	In=Out=Exhaust=3/8 "
압력 범위:	0.15 0.8MPa에	맥스 압력저항:	1.2 MPa
본체 소재:	알루미늄 합금	배선용 형식:	와이어 또는 DIN43650 연결기를 이끄세요
전압:	12VDC, 24VDC, 24VAC, 110VAC, 220VAC
하이 라이트:	Pneumatic Solenoid Valve 24V DC 220V AC , Pneumatic Control Solenoid Valve , VF5120 SMC

VF5120 SMC Type 5/2 Way Solenoid Pneumatic Valve 24V DC 220V AC

Pneumatic solenoid valves can be found in a wide range of industries. They are used in Pneumatic Artificial Muscles (PAM) for robotics and automation. Manufacturing companies that use conveyors belts uses pneumatic valves in their conveyor belt systems. Food and beverage manufacturers use them to make, dispense or preserve food and beverage products.

BRNADO pneumatic valves offer reliability, low power consumption, and have a long life. They are have prewired connections that makes installation, maintenance, and control simple.

Technial Data of VF & VZ Series Pneumatic Solenoid Valves:

Model	VF3130	VF33(4/5)30	VF5120	VF53(4/5)50	VZ5120	VZ53(4/5)50
Model	VF3230	VF33(4/5)30	VF5220	VF53(4/5)50	VZ5220	VZ53(4/5)50
Valve Type	5/2 way	5/3 way	5/2 way	5/3 way	5/2 way	5/3 way
Orifice Size	16mm² (Cv=0.89)	12mm² (Cv=0.67)	25mm² (Cv=1.4)	18mm² (Cv=1)	12mm² (Cv=0.67)	9mm² (Cv=0.50)
Fluid	Air (to be filtered by 40 μm filter element)
Operating Pressure	0.15 to 0.8 MPa
Proof Pressure	1.2 MPa
Body Material	Aluminum Alloy
Max Frequency	5 cycle / sec
Voltage	12VDC, 24VDC, 24VAC, 110VAC, 220VAC
Wire Form	Lead Wire or DIN43650 Connector

Dimension of VF5120 Pneumatic Solenoid Valve:

VF5120 SMC Type 5/2 Way Solenoid Pneumatic Valve 24V DC 220V AC 0

Production Video of Pneumatic Solenoid Valve:
