| 원래 장소: | 닝보, 중국 |
| 브랜드 이름: | BRANDO |
| 인증: | None |
| 모델 번호: | TH-4820-B |
| 최소 주문 수량: | 8pcs |
|---|---|
| 가격: | 협상 가능 |
| 포장 세부 사항: | 상자, 상자, 팔레트 |
| 배달 시간: | 결제 완료 후 약 4~7 영업일 소요 |
| 지불 조건: | T/T, PayPal, Western Union |
| 공급 능력: | 한 달에 50000pc |
| 제품 이름: | 펄스 밸브 | 포트 크기: | 3/4 '' |
|---|---|---|---|
| 신체 재료: | 알루미늄 (다이 캐스트) | 다이어프램 재료: | NBR |
| 작동 압력: | 0.35 내지 8.5 바 | 전압: | 24VDC, 24VAC, 110VAC, 220VAC |
| 애플리케이션: | 흡진장치 | ||
| 강조하다: | TAEHA Pulse Valve TH-4820-B,TAEHA Pulse Valve 3/4'',TAEHA Pulse Jet Valve |
||
TH-4820-B 3/4'' TAEHA Type Pulse Valve
Pulse Jet Valve, also called diaphragm valve acts as a "switch" for compressed air in the dust collector system for bag filters. It is controlled by the electric signals from the Pulse Controller. Pulse Jet Valves are used in filtering systems of dust collectors, gas turbines, and desulfurization equipment. Pulse jet valves are commonly used to clean filters such as cartridge filters, envelope filters, ceramic filters, and sintered metal fiber filters.
Different pulse jet valve structure:
1. Threaded Type
2. Manifold Flat Mount Type
3. Dresser Nut Type
4. Straight Through Type
5. Flanged Type
Technical Data:
| Integral Pilot Model | TH-4820-B | TH-4825-B | TH-4830-B | TH-4430-B | TH-4840-B | TH-4440-B | TH-4450-B | TH-4460-B | TH-4475-B |
| Remote Pilot Model | TH-5820-B | TH-5825-B | TH-5830-B | TH-5430-B | TH-5840-B | TH-5440-B | TH-5450-B | TH-5460-B | TH-5475-B |
| Port Size | 3/4'' | 1'' | 1-1/4'' | 1-1/4'' | 1-1/2'' | 1-1/2'' | 2'' | 2-1/2'' | 3'' |
| Pilot Size | 1/4'' | ||||||||
| Diaphragm Number | 1 | 1 | 1 | 2 | 1 | 2 | 2 | 2 | 2 |
| Working pressure | 0.35 to 8.5 bar | ||||||||
| Diaphragm Material | NBR | ||||||||
| Body Material | Aluminum (diecast) | ||||||||
| Voltage | 24VAC, 110VAC, 220VAC, 24VDC | ||||||||
TH-4820-B Dimension:
Our Production:
Related Products:
|
|
|
|
|
| Solenoid Coil | Solenoid Armature | Diaphragm | Pulse Controller |
Focus on your demands, Offer you best solution:
√ Contact us if some points you have doubt
√ Contact us if somewhere need to change
√ Contact us if not the one you are looking for
√ Contact us if you are doing designing
Welcome to your any question and inquiry!
