제품 소개맥박 제트기 벨브

FAP-B-1 Pulse Valve Bulkhead Connector for Dust Collector Air Header Tank

FAP-B-1 Pulse Valve Bulkhead Connector for Dust Collector Air Header Tank

  • FAP-B-1 Pulse Valve Bulkhead Connector for Dust Collector Air Header Tank
FAP-B-1 Pulse Valve Bulkhead Connector for Dust Collector Air Header Tank
제품 상세 정보:
원래 장소: 닝보, 중국
브랜드 이름: BRANDO
인증: None
모델 번호: FAP-B-1
결제 및 배송 조건:
최소 주문 수량: 20pcs
가격: 협상 가능
포장 세부 사항: 상자, 상자, 팔레트
배달 시간: 4 내지 7 근무일
지불 조건: T/T, PayPal, Western Union
공급 능력: 한 달에 100000pc
접촉
상세 제품 설명
제품 이름: 벌크 헤드 커넥터 유형: 스레드 파이프가있는 싱글 드레서 너트
크기: 1 '', 1-1/2 ''(DN25, DN40) 너트와 바디 재료: 알류미늄
밀봉 및 개스킷 재료: NBR (표준), FKM (선택)
강조하다:

Bulkhead Connector FAP-B-1

,

Pulse Valve Bulkhead Connectors

,

Bulkhead Connectors for Pulse Valve

FAP-B-1 Bulkhead Connector



A pulse valve bulkhead connector is a specialized adapter that creates a secure, through-wall connection for the pneumatic or electrical components of a reverse pulse jet valve system, commonly used in industrial dust collectors. It acts as a sealed pass-through, simplifying the installation and maintenance of these cleaning valves by eliminating the need for welding and allowing for easy removal of the valve components from one side of the dust collector's housing.

Key Features
1) Various Sizes: available in multiple sizes (e.g., 3/4", 1", 1-1/2", 2'', 2-1/2'', 3'') to match different pulse valves and piping.
2) Material: often made from pressure die-casted aluminum or other robust materials suitable for industrial environments.
3) Sealing: come with specific seals (like NBR or FKM for different temperature ranges) to create a secure seal against the collector wall.



Main Dimension:
FAP-B-1 Pulse Valve Bulkhead Connector for Dust Collector Air Header Tank 0
Model No
FAP-B-1-25
FAP-B-1-40
DN
25
40
L
237
302
L1
176
236
L2
24
28
D
51
54
ΦA
Φ34
Φ48
M
G1''
G1-1/2''
ΦC
Φ48
Φ60



Installation:
FAP-B-1 Pulse Valve Bulkhead Connector for Dust Collector Air Header Tank 1

More Bulkhead Connectors:
FAP-B-1 Pulse Valve Bulkhead Connector for Dust Collector Air Header Tank 2


Our Production:

FAP-B-1 Pulse Valve Bulkhead Connector for Dust Collector Air Header Tank 3



Related Products:

FAP-B-1 Pulse Valve Bulkhead Connector for Dust Collector Air Header Tank 4 FAP-B-1 Pulse Valve Bulkhead Connector for Dust Collector Air Header Tank 5 FAP-B-1 Pulse Valve Bulkhead Connector for Dust Collector Air Header Tank 6 FAP-B-1 Pulse Valve Bulkhead Connector for Dust Collector Air Header Tank 7 FAP-B-1 Pulse Valve Bulkhead Connector for Dust Collector Air Header Tank 8
Coil Armature Diaphragm Pulse Valve Pulse Controller
