제품 소개맥박 제트기 벨브

FAP-C FAP-C-1 Bulkhead Connector for Dust Collector Pulse Jet Valve

FAP-C FAP-C-1 Bulkhead Connector for Dust Collector Pulse Jet Valve

  • FAP-C FAP-C-1 Bulkhead Connector for Dust Collector Pulse Jet Valve
FAP-C FAP-C-1 Bulkhead Connector for Dust Collector Pulse Jet Valve
제품 상세 정보:
원래 장소: 닝보, 중국
브랜드 이름: BRANDO
인증: None
모델 번호: fap-c
결제 및 배송 조건:
최소 주문 수량: 20pcs
가격: 협상 가능
포장 세부 사항: 상자, 상자, 팔레트
배달 시간: 4 내지 7 근무일
지불 조건: T/T, PayPal, Western Union
공급 능력: 한 달에 100000pc
접촉
상세 제품 설명
제품 이름: 벌크 헤드 커넥터 크기: 3/4 '', 1 '', 1-1/2 '', 2 ''(DN20, DN25, DN40, DN50)
너트와 바디 재료: 알류미늄 밀봉 및 개스킷 재료: NBR (표준), FKM (선택)
강조하다:

Bulkhead Connector FAP-C

,

Pulse Jet Valve Bulkhead Connector

,

Pulse Jet Valve Bulkhead Fitting

FAP-C Bulkhead Connector



A pulse valve bulkhead connector is a specialized adapter that creates a secure, through-wall connection for the pneumatic or electrical components of a reverse pulse jet valve system, commonly used in industrial dust collectors. It acts as a sealed pass-through, simplifying the installation and maintenance of these cleaning valves by eliminating the need for welding and allowing for easy removal of the valve components from one side of the dust collector's housing.

Key Features
1) Various Sizes: available in multiple sizes (e.g., 3/4", 1", 1-1/2", 2'', 2-1/2'', 3'') to match different pulse valves and piping.
2) Material: often made from pressure die-casted aluminum or other robust materials suitable for industrial environments.
3) Sealing: come with specific seals (like NBR or FKM for different temperature ranges) to create a secure seal against the collector wall.



Main Dimension:
FAP-C FAP-C-1 Bulkhead Connector for Dust Collector Pulse Jet Valve 0
Model No FAP-C-1-20 FAP-C-1-25 FAP-C-1-40 FAP-C-1-50
DN 20 25 40 50
L 118 130 144 162
L1 110 120 130 144
L2 32 40 42
M G3/4'' G1'' G1-1/2'' G2''
ΦC Φ41 Φ50 Φ66 Φ78



Installation:
FAP-C FAP-C-1 Bulkhead Connector for Dust Collector Pulse Jet Valve 1

More Bulkhead Connectors:
FAP-C FAP-C-1 Bulkhead Connector for Dust Collector Pulse Jet Valve 2


Our Production:

FAP-C FAP-C-1 Bulkhead Connector for Dust Collector Pulse Jet Valve 3



Related Products:

FAP-C FAP-C-1 Bulkhead Connector for Dust Collector Pulse Jet Valve 4 FAP-C FAP-C-1 Bulkhead Connector for Dust Collector Pulse Jet Valve 5 FAP-C FAP-C-1 Bulkhead Connector for Dust Collector Pulse Jet Valve 6 FAP-C FAP-C-1 Bulkhead Connector for Dust Collector Pulse Jet Valve 7 FAP-C FAP-C-1 Bulkhead Connector for Dust Collector Pulse Jet Valve 8
Coil Armature Diaphragm Pulse Valve Pulse Controller
