| 원래 장소: | 중국 닝보 |
| 브랜드 이름: | BRANDO |
| 인증: | None |
| 모델 번호: | BB14040007 |
| 최소 주문 수량: | 200 |
|---|---|
| 가격: | 협상 가능 |
| 포장 세부 사항: | 내부 상자, 상자, 팔레트 |
| 배달 시간: | 협상 |
| 지불 조건: | T/T, 페이팔, 웨스턴 유니온 |
| 공급 능력: | 한 달에 200000 PC |
| 제품명: | 펄스 밸브 솔레노이드 코일 | 주문 코드: | 400425-142, 400425-117 |
|---|---|---|---|
| 전압: | 24VDC, 220VAC | 힘: | 9.5W, 10.5W, 11.2W |
| 절연 등급: | H, F | 온도 클래스: | 티, 비, 에프 |
| 커넥터: | DIN43650A | 장착 된 펄스 밸브 모델: | SCG353A047, SCG353A050, SCG353A051 |
| 강조하다: | ASCO 400425-142 Solenoid Coil,ASCO Solenoid Coil 24VDC,ASCO Pulse Valve Solenoid Coil 24V |
||
ASCO Type Dust Collector Pulse Valve Solenoid Coil 400425-142 24VDC 11.2W
This is a solenoid coil for asco pulse valve SCG353A047, SCG353A050, SCG353A051; ordering code: 400425-142, 400425-117; voltage: 24VDC, 220VAC; power: 9.5W, 10.5W, 11.2W; insulation class: H, F; temperature class: T, B, F; connector type: DIN 43650 Form A.
Pulse jet valves are indirect operated solenoid valves especially designed for dust collector systems. When the solenoid is energized, trapped air above a diaphragm is quickly exhausted causing a high pressure difference across the diaphragm. Thereby the diaphragm is suddenly opened. When the solenoid is de-energized, air escapes through a hole to the chamber above the diaphragm which balances the pressure and instantly closes the valve.
Ordering Code of Solenoid Valve Coil:
Dimension & Data of Solenoid Coil, Armature for ASCO Pulse Valve:
![]()
![]()
Video of 400425-142, 400425-117 Solenoid Coil:
BRANDO Solenoid Valve Coils Production Video:
More ASCO Type Pulse Valves for you to choose:
| Threaded Type | Remote Pilot Type | Straight Through Type | Submerged Type |
| Diaphragm | Solenoid Coil | Solenoid Armature | Pulse Controller |
Focus on your demands, Offer you best solution:
√ Contact us if some points you have doubt
√ Contact us if somewhere need to change
√ Contact us if not the one you are looking for
√ Contact us if you are doing designing
Welcome to your any question and inquiry!
