| 원래 장소: | 중국 |
| 브랜드 이름: | Brando |
| 인증: | None |
| 모델 번호: | RCA3D |
| 최소 주문 수량: | 1개 |
|---|---|
| 가격: | 협상 가능 |
| 포장 세부 사항: | 내부 상자, 상자, 팔레트 |
| 배달 시간: | 4 내지 7 근무일 |
| 지불 조건: | T/T, 페이팔, 웨스턴 유니온 |
| 공급 능력: | 달 당 100000pcs |
| 포트 크기: | 1/8 '' | 스레드 유형: | NPT, BSPP |
|---|---|---|---|
| 밸브 구조: | 직각, 나사산 포트 | 씰 재질: | NBR, FKM |
| 작동 압력 범위: | 0 ~ 0.85 MPa | 코일 전압: | 12VDC, 24VDC, 24VAC, 110VAC, 220VAC |
| 강조하다: | GOYEN RCA3D,RCA3D pilot valves,rca3 solenoid pilot valves |
||
RCA3D Goyen Type Remote Pilot Valve RCA3D0 RCA3D1 RCA3D2 24V 110V 220V
Solenoid pilot valves are specifically designed for the reverse pulse jet filter cleaning of dust collectors and baghouses. These include all variations of bag filters, cartridge filters, envelope filters, ceramic filters and sintered metal fiber filters. Their tough and reliable construction makes them perfectly suited for both noxious and environmental dust collection applications in a wide range of industries, including:
1. Cement dust collection
2. Mining dust collection
3. Silo/bulk materials handling dust collection
4. Industrial dust collection
5. Power industry: protection of boilers and gas turbine intake filter systems
Ordering Code of RCA3D Solenoid Pilot Valve:
|
Model
|
Port Size
|
Coil Type
|
Voltage
|
Power
|
|
RCA3D0-330
(Old RCA3D2-T-QT/1392B)
|
1/8''
|
Screw / Spade
|
200/240V 50/60Hz
|
17.4/22.6VA
|
|
RCA3D0-331
(Old RCA3D2-T-QT/1004B)
|
100/120V 50/60Hz
|
15.2/149.7VA
|
||
|
RCA3D0-332
|
24V 50/60Hz
|
23.1/17.2VA
|
||
|
RCA3D0-333
|
240V DC
|
24W
|
||
|
RCA3D0-334
|
110V DC
|
24W
|
||
|
RCA3D0-335
|
48V DC
|
20W
|
||
|
RCA3D0-336
(Old RCA3D2-T-QT/764B)
|
24V DC
|
20W
|
||
|
RCA3D0-337
(Old RCA3D2-T-QT/1295B)
|
12V DC
|
20W
|
||
|
RCA3D1-330
|
1/8'' BSPP
|
200/240V 50/60Hz
|
17.4/22.6VA
|
|
|
RCA3D1-331
|
100/120V 50/60Hz
|
15.2/149.7VA
|
||
|
RCA3D1-332
|
24V 50/60Hz
|
23.1/17.2VA
|
||
|
RCA3D1-333
|
240V DC
|
24W
|
||
|
RCA3D1-334
|
110V DC
|
24W
|
||
|
RCA3D1-335
|
48V DC
|
20W
|
||
|
RCA3D1-336
|
24V DC
|
20W
|
||
|
RCA3D1-337
|
12V DC
|
20W
|
Main Dimension of RCA3D Solenoid Pilot Valve:
Video of RCA3D Solenoid Pilot Valve:
Enclosure for RCA3D Solenoid Pilot Valve:
More Goyen Type Pulse Valves for you to choose:
|
|
|
|
| T Series | DD Series | FS Series | MM Series |
|
|
|
|
| RCA Series | Solenoid Coil | Solenoid Armature | Diaphragm |
