| 원래 장소: | 중국 닝보 |
| 브랜드 이름: | BRANDO |
| 인증: | None |
| 모델 번호: | 6.16BAP030BM8 |
| 최소 주문 수량: | 200 |
|---|---|
| 가격: | 협상 가능 |
| 포장 세부 사항: | 안 상자, 판지, 깔판 |
| 배달 시간: | 협상 |
| 지불 조건: | T/T, 페이팔, 웨스턴 유니온 |
| 공급 능력: | 달 당 100000pcs |
| 기능: | 정상적으로 마무리되는 2가지 방식 | 포트 크기: | M8 |
|---|---|---|---|
| 오리피스 크기: | 3mm | 밸브 본체 재질: | PTFE |
| 씰 재질: | PTFE | 작동 압력 범위: | 0~0.3MPa |
| 전압: | 12VDC, 24VDC, 110VAC, 220VAC | ||
| 강조하다: | M8 PTFE Solenoid Valve,M8 Anti-corrosive PTFE Solenoid Valve,Anti Corrosion Solenoid Valve 24V |
||
M8 Anti-corrosive Isolation PTFE Solenoid Valve DC24V AC220V
Product Features:
Our isolation solenoid valves offer instrument designers a completely inert, non-metallic fluid path. The valves use a flexible diaphragm to isolate the solenoid actuation mechanism from the fluid path. Isolation Valves offer low internal volumes, precise flow control and excellent ease of installation making them particularly suitable for use in highly aggressive and / or high purity fluid applications such as analytical chemistry and clinical diagnostics. The highly inert fluid path is especially useful in liquid chromatography, genomics and protein synthesis applications. The high flow factor makes these valves well suited to environmental and water analysis applications.
Technical Data of Isolation Solenoid Valve:
| Model No. | Port size | Orifice (mm) | Cv | Mini Pressure | Max Pressure | Seal Material | |||
| AC(6VA) | DC(10W) | ||||||||
| 6.16BAP030BM8 | M8x1 | 3.0 | 0.1 | 0.0MPa | 0.3MPa | 0.3MPa | PTFE | ||
| 6.16BAP030B01 | 1/8'' | 3.0 | 0.1 | 0.0MPa | 0.3MPa | 0.3MPa | |||
| 6.16BAP030B02 | 1/4'' | 3.0 | 0.1 | 0.0MPa | 0.15MPa | 0.15MPa | |||
| AC(24VA) | DC(13W) | ||||||||
| 6.16BAP060B02 | 1/4'' | 6.0 | 0.28 | 0.0MPa | 0.15MPa | 0.15MPa | |||
| 6.16BAP060B03 | 3/8'' | 6.0 | 0.28 | 0.0MPa | 0.15MPa | 0.15MPa | |||
| 6.16BAP060B04 | 1/2'' | 6.0 | 0.28 | 0.0MPa | 0.15MPa | 0.15MPa | |||
| 6.16BAP060B06 | 3/4'' | 6.0 | 0.28 | 0.0MPa | 0.15MPa | 0.15MPa | |||
Main Dimension of Isolation Solenoid Valve:
