당신의 수요에 초점
당신에게 제일 해결책을 제안하십시오
영업 및 지원:
 |
| 원래 장소: | 중국 닝보 |
| 브랜드 이름: | BRANDO |
| 인증: | None |
| 모델 번호: | 6.16DAP20B06 |
| 최소 주문 수량: | 200 |
|---|---|
| 가격: | 협상 가능 |
| 포장 세부 사항: | 안 상자, 판지, 깔판 |
| 배달 시간: | 협상 |
| 지불 조건: | T/T, 페이팔, 웨스턴 유니온 |
| 공급 능력: | 달 당 100000pcs |
| 기능: | 정상적으로 마무리되는 2가지 방식 | 포트 크기: | 3/4'' |
|---|---|---|---|
| 오리피스 크기: | 20mm | 밸브 본체 재질: | PTFE |
| 씰 재질: | EPDM, FKM, PTFE | 작동 압력 범위: | 00.01~0.6MPa |
| 전압: | 12VDC, 24VDC, 110VAC, 220VAC | 작업: | 피스톤 파일럿은 작동했습니다 |
| 작동 매체: | 화학물질, 산, 알칼리, 부식성 액체 등 | ||
| 강조하다: | 3/4'' PTFE Solenoid Valve,Anti Corrosion Solenoid Valve 3/4'',Anti Corrosion Solenoid Valve 220V |
||
3/4'' Anti-corrosion PTFE Solenoid Valve DC24V AC110V AC220V
This is an anti corrosive PTFE solenoid valve, 3/4'' female threaded port size, 20mm orifice size, 2/2 way normally closed, pilot piston operated, 0.01 to 0.6 MPa working pressure, can be EPDM, FKM or PTFE seal to suit different working mediums, various voltages for your choice, such as 12VDC, 24VDC, 24VAC, 110VAC and 220VAC, etc. It is used for a wide arrange of industrial applications to control fluids.
Technical Data:
|
Model No
|
Port Size
|
Orifice Size
|
CV
|
Working Pressure
|
Body Material
|
Seal Material
|
Function
|
Voltage
|
|
6.16DAP15B04
|
1/2''
|
15mm
|
4
|
0 to 6 bar
|
PTFE
|
EPDM
FKM
PTFE
|
2 Way NC
|
12VDC
24VDC
24VAC
110VAC
220VAC
|
|
6.16DAP20B06
|
3/4''
|
20mm
|
5.5
|
|||||
|
6.16DAP25B25
|
1''
|
25mm
|
13
|
|||||
|
6.16DAP32B32
|
1-1/4''
|
32mm
|
17
|
|||||
|
6.16DAP40B40
|
1-1/2''
|
40mm
|
25
|
|||||
|
6.16DAP50B50
|
2''
|
50mm
|
40
|
|||||
|
6.16DAP65B65
|
2-1/2''
|
60mm
|
62
|
|
Model No
|
Dimension
|
||||||||
|
P
|
D
|
H
|
E
|
A
|
M
|
L
|
K
|
F
|
|
|
6.16DAP15B04
|
1/2''
|
70
|
127
|
56.5
|
18.5
|
M5
|
14
|
92
|
58
|
|
6.16DAP20B06
|
3/4''
|
80
|
136
|
70.5
|
20
|
M6
|
10
|
92
|
67
|
|
6.16DAP25B25
|
1''
|
95
|
145
|
78
|
25
|
M6
|
12
|
92
|
75
|
|
6.16DAP32B32
|
1-1/4''
|
120
|
200
|
110
|
31
|
M8
|
20
|
94
|
98
|
|
6.16DAP40B40
|
1-1/2''
|
130
|
220
|
113
|
33.5
|
M8
|
18
|
94
|
106
|
|
6.16DAP50B50
|
2''
|
150
|
249
|
140
|
43
|
M10
|
20
|
94
|
116
|
|
6.16DAP65B65
|
2-1/2''
|
180
|
262
|
152
|
49
|
M10
|
25
|
94
|
116
|
Our Production:
FAQ:
Question 1: What is a solenoid valve used for?
Answer 1: A solenoid valve is used to open, close, mix, or divert media in an application. They are used in a wide variety of applications.
Question 2: How can you tell if your solenoid valve is bad?
Answer 2: If the solenoid valve fails to open or close, is partially open, makes a humming noise or has a burned-out solenoid coil, you need to troubleshoot the valve solenoids.
Question 3: How do I choose a solenoid valve?
Answer 3: When choosing a solenoid valve, it is important to know your media. Depending upon the media and flow requirement, choose the material, port size, orifice size, temperature, pressure, voltage, response time and certification required for your application.
