| 원래 장소: | 중국 |
| 브랜드 이름: | BRANDO |
| 인증: | None |
| 모델 번호: | CMV-8S |
| 최소 주문 수량: | 5개 |
|---|---|
| 가격: | 협상 가능 |
| 포장 세부 사항: | 내부 상자, 판지, 팔레트 |
| 배달 시간: | 협상 |
| 지불 조건: | T/T,웨스턴 유니온,머니그램 |
| 공급 능력: | 달 당 100000 PC |
| 제품명: | 냉동 체크 밸브 | 포트 크기: | 1/2" |
|---|---|---|---|
| 연결 유형: | 솔더 | 호환성: | CFC, HCFC (수소염화불화탄소), HFC와 HFO 냉각제와 오일 |
| 최대 작동 압력: | 55개 바 최고 5/8까지 " 사이즈 | 작동 온도: | 149' Ｃ에 대한 -40' Ｃ |
| 강조하다: | Mueller Magnetic Check Valve cmv-8s,Mueller Magnetic Check Valve 1/2'',Refrigeration Magnetic Check Valve cmv-8s |
||
Mueller Type Refrigeration Magnetic Check Valve CMV-8S 1/2'' Solder
Magnetic type refrigeration check valve is designed for installation in commercial refrigerating systems and in residential or industrial air conditioning plants. They are used to control the unidirectional flow of refrigerant to prevent backflow; the magnetic actuator guarantees a high reliability standard. When you install the refrigeration check valve in the system, it will rapidly balance the high pressure and low pressure inside of the compressor when the compressor stops working, when it reaches balance, then the refrigerants won't flow until the air conditioning or the refrigeration unit restarts.
Technical Data of CMV Series Magnetic Check Valve:
| Model |
Connection Size (ODF) |
Max Working Presure
(bar)
|
Cv Value | Max. Internal Leak |
| CMV-4S | 1/4'' | 55 | 0.7 | <2.3 ml/min |
| CMV-6S | 3/8'' | 55 | 1.2 | <2.3 ml/min |
| CMV-8S | 1/2'' | 48 | 2.7 | <3.3 ml/min |
| CMV-10S | 5/8'' | 48 | 3.3 | <3.3 ml/min |
| CMV-12S | 3/4'' | 48 | 7.2 | <6.6 ml/min |
| CMV-14S | 7/8'' | 48 | 8.0 | <6.6 ml/min |
| CMV-18S | 1 1/8'' | 48 | 13.2 | <13.1 ml/min |
| CMV-22S | 1 3/8'' | 48 | 18.9 | <13.1 ml/min |
| CMV-26S | 1 5/8'' | 48 | 27.8 | <19.7 ml/min |
| CMV-34S | 2 1/8'' | 48 | 49.9 | <19.7 ml/min |
| CMV-42S | 2 5/8'' | 48 | 61.9 | <26.2 ml/min |
| CMV-50S | 3 1/8'' | 45 | 64.1 | <26.2 ml/min |
Main Dimension of CMV Series Magnetic Check Valve:
| Model | Connection Size | Dimension | ||||||
| inch | mm | A | B | D | ||||
| inch | mm | inch | mm | inch | mm | |||
| CMV-4 | 1/4'' | 6 | 4.02 | 102 | 0.88 | 22 | 0.34 | 9 |
| CMV-6 | 3/8'' | 10 | 4.02 | 102 | 0.88 | 22 | 0.34 | 9 |
| CMV-8 | 1/2'' | 13 | 5.18 | 131 | 1.13 | 29 | 0.41 | 10 |
| CMV-10 | 5/8'' | 16 | 5.18 | 131 | 1.13 | 29 | 0.53 | 13 |
| CMV-12 | 3/4'' | 19 | 7.04 | 179 | 1.63 | 41 | 0.65 | 17 |
| CMV-14 | 7/8'' | 22 | 7.04 | 179 | 1.63 | 41 | 0.78 | 20 |
| CMV-18 | 1 1/8'' | 29 | 8.43 | 214 | 2.13 | 54 | 0.94 | 24 |
| CMV-22 | 1 3/8'' | 35 | 9.41 | 239 | 2.63 | 67 | 1.00 | 25 |
| CMV-26 | 1 5/8'' | 41 | 10.55 | 268 | 3.13 | 79 | 1.12 | 28 |
| CMV-34 | 2 1/8'' | 54 | 12.06 | 306 | 3.63 | 92 | 1.37 | 35 |
| CMV-42 | 2 5/8'' | 67 | 13.05 | 331 | 4.13 | 105 | 1.50 | 38 |
| CMV-50S | 3 1/8'' | 79 | 13.05 | 331 | 4.13 | 105 | 1.69 | 43 |
Cross Reference of Refrigeration Magnetic Check Valves:
| MUELLER | Model No. | HENRY | SUPERIOR |
| CMV-4S | ACK-4 | MS-4 | 900MA-4S |
| CMV-6S | ACK-6 | MS-6 | 900MA-6S |
| CMV-8S | ACK-8 | MS-8 | 900MA-8S |
| CMV-10S | ACK-10 | MS-10 | 900MA-10S |
| CMV-12S | ACK-12 | MS-12 | 900MA-12S |
| CMV-14S | ACK-14 | MS-14 | 900MA-14S |
| CMV-18S | ACK-18 | MS-18 | 900MA-11S |
| CMV-22S | ACK-22 | MS-22 | 900MA-13S |
| CMV-26S | ACK-26 | MS-26 | 900MA-15S |
| CMV-34S | ACK-34 | MS-34 | 900MA-21S |
| CMV-42S | ACK-42 | MS-42 | 900MA-25S |
| CMV-50S | / | / | / |
