| 원래 장소: | 중국 닝보 |
| 브랜드 이름: | BRANDO |
| 인증: | None |
| 모델 번호: | BB09030027 |
| 최소 주문 수량: | 200 |
|---|---|
| 가격: | 협상 가능 |
| 포장 세부 사항: | 내부 상자, 판지, 팔레트 |
| 배달 시간: | 협상 |
| 지불 조건: | T/T, 페이팔, 웨스턴 유니온 |
| 공급 능력: | 달 당 250000 조각 |
| 제품명: | 솔레노이드 밸브 코일 | 전압: | 12VDC, 24VDC, 24VAC, 110VAC, 220VAC |
|---|---|---|---|
| 힘: | 2W, 3W, 6W, 7W, 7.5W, 2.5VA, 5VA, 7VA, 8VA | 커넥터: | DIN43650A |
| 보호 등급: | IP65 | 절연 등급: | f, h |
| 강조하다: | Pneumatic Solenoid Valve Coil CNOMO,CNOMO Solenoid Valve Coil 12V,CNOMO Electrical Coil 24V |
||
CNOMO Pneumatic Solenoid Valve Coil 30mm 3/2 Way 12V 24V 110V 220V
This solenoid coil is same with AMISCO EVI 30/9, which is popularly used in CNOMO 30mm pneumatic solenoid valves. Voltage: 12VDC, 24VDC, 24VAC, 110VAC, 220VAC. Power: 2W, 3W, 6W, 7W, 7.5W, 2.5VA, 5VA, 7VA, 8VA. CNOMO direct solenoid valves are poppet valves 3 ways, ready to be assembled on the 06-05-80 CNOMO standard base. Available in the normally closed and normally opened version with or without manual operator. As standard, manual operator works with push and push+turn function in order to satisfy all needs.
Dimension & Data of Solenoid Valve Coil, Armature:
|
BRANDO Model
|
BB09030027
|
|
Voltage
|
12VDC, 24VDC, 24VAC,
110VAC, 220VAC
|
|
Power
|
2W, 3W, 6W, 7W, 7.5W,
2.5VA, 5VA, 7VA, 8VA
|
|
Other voltage and power can be customized
|
|
|
Connector
|
DIN43650B
|
|
Insulation Class
|
F, H
|
|
BRANDO Model
|
BAPC308932018
|
|
Function
|
3 Way Normally Closed
|
|
Plunger Tube Material
|
Brass
|
|
Seal Material
|
NBR, EPDM, FKM
|
|
Connection Type
|
Flange With O-ring Groove
|
Video of Solenoid Valve Coil:
BRANDO Solenoid Valve Coils Production Video:
