| 원래 장소: | 중국 |
| 브랜드 이름: | BRANDO |
| 인증: | CE, ISO |
| 모델 번호: | C113825 |
| 최소 주문 수량: | 1 세트 |
|---|---|
| 가격: | 협상 가능 |
| 포장 세부 사항: | 플라스틱 봉지, 상자, 카튼, 팔렛 |
| 배달 시간: | 4 내지 7 근무일 |
| 지불 조건: | L/C,T/T,Paypal,Western 통합 |
| 공급 능력: | 한 달에 10 만 세트 |
| 제품명: | 펄스 밸브 다이어프램 | 주문 코드: | C113825, C1138-25 |
|---|---|---|---|
| 다이어프램 재료: | NBR, FKM | 1 세트: | 1pc 다이어프램, 1pc 스프링 |
| 장착된 펄스 밸브 포트 크기: | 1.5 '' | 장착 된 펄스 밸브 모델: | G353A045 |
| 강조하다: | ASCO Diaphragm C113825,ASCO Membrane C113825,C113825 Pulse Valve Diaphragm |
||
C113825 C113-825 Diaphragm Repair Kit For G353A045 ASCO Pulse Jet Valve 1.5''
C113825, C1138-25 Diaphragm (Membrane) for ASCO pulse valve G353A045; NBR material is standard, working temperature range is -5 to +80 ℃; Viton material is optional, for high temperature, working temperature range is -10 to +120 ℃. Pulse Jet Valve is a solenoid pilot operated diaphragm valve specially designed to deliver extremely fast pulsing in reverse-jet dust collector systems. With its high flow rates, higher peak pressure and the fastest response times on the market it delivers optimal filter cleaning performance, while using significantly less air. This results in energy savings for the user.
Ordering Number of Diaphragm For ASCO Pulse Valve:
|
Valve Port Size
|
Pulse Valve Model
|
Diaphragm Model
|
Diaphragm Material
(FKM is also available)
|
|
3/4''
|
SCG353A043
|
C113444
|
TPE (White), NBR (Black)
|
|
1''
|
SCG353A044
|
||
|
3/4''
|
SCG353-052
|
||
|
1''
|
SCG353-053
|
||
|
3/4''
|
SGG353A043
|
||
|
1''
|
SGG353A044
|
||
|
3/4''
|
SGG353-052
|
||
|
1''
|
SGG353-053
|
||
|
1 1/2''
|
SCG353A047
|
C113827
|
NBR
|
|
SGG353A065
|
|||
|
2''
|
SCG353A050
|
C113685, C113686
|
NBR
|
|
2 1/2''
|
SCG353A051
|
||
|
3''
|
SCXE353.060
|
C123432, C123433
|
NBR
|
|
SCG353D060
|
|||
|
3/4''
|
G3530A41
|
C113443
|
NBR
|
|
1''
|
G353A042
|
||
|
3/4''
|
G353-055
|
||
|
1''
|
G353-056
|
||
|
1 1/2''
|
G353A045
|
C113825
|
NBR
|
|
G353-066
|
|||
|
1 1/2''
|
G353A046
|
C113826
|
NBR
|
|
G353A063
|
|||
|
2''
|
G353A048
|
C113684
|
NBR
|
|
2 1/2''
|
G353A049
|
Main Dimension of C113825 Diaphragm:
Product Video of C113825 Membrane:
Pictures of Pulse Valve Diaphragm Production:
More Related Products For you to choose:
|
|
|
|
| Threaded Type | Remote Pilot Type | Straight Through Type | Submerged Type |
|
|
|
|
| Diaphragm | Solenoid Coil | Solenoid Armature | Pulse Controller |
