| 원래 장소: | 중국 |
| 브랜드 이름: | Brando |
| 인증: | None |
| 모델 번호: | DB116 |
| 최소 주문 수량: | 1세트 |
|---|---|
| 가격: | 협상 가능 |
| 포장 세부 사항: | 플라스틱 봉지, 상자, 카튼, 팔렛 |
| 배달 시간: | 4 내지 7 근무일 |
| 지불 조건: | T/T, 웨스턴 유니온, 페이팔 |
| 공급 능력: | 한 달에 10 만 세트 |
| 제품명: | 펄스 밸브 다이어프램 | 다이어프램 재료: | NBR, Viton |
|---|---|---|---|
| 1세트: | 1개 pc DB116 진동판, 1개 pc DB16 진동판, 2 PC 봄 | 장착 된 펄스 밸브 모델: | VNP216, VEM216, VNP416, VEM416, VNP616, VEM616, VNP716, VEM716 |
| 강조하다: | Mecair Diaphragm DB116/C,Mecair Membrane DB116/C,DB116 Membrane Kit |
||
DB116 DB116/C Diaphragm Repair Kit For Mecair Pulse Jet Valve 2 Inch VNP216 VNP416
DB116 ( DB116/C ) Diaphragm ( Membrane ) for Mecair pulse valve VNP216, VEM216, VNP416, VEM416, VNP616, VEM616, VNP716, VEM716; NBR material is standard, working temperature range is -5 to +80 ℃; Viton material is optional, for high temperature, working temperature range is -10 to +120 ℃. Pulse Jet valves are indirect type solenoid valves. When the solenoid of pulse jet valves gets energized, air trapped in the diaphragm is exhausted causing pressure difference in the diaphragm. Then the diaphragm is suddenly opened. When it is de-energized, air passes through the hole to the chamber which can balance the air pressure and close the valve. The opening and closing of the valve are done very fast for filter cleaning and consumption of compressed air effectively.
Ordering Code of Diaphragm For Mecair Pulse Valve:
|
Ordering code
|
Fitted valve code
|
Valve port size
|
Material
|
|
DB16/G
|
VNP206, VEM206, VNP306, VEM306
|
3/4''
|
NBR
|
|
DB18/G
|
VNP208, VEM208, VNP308, VEM308,
VNP408, VEM408
|
1''
|
NBR
|
|
DB18M
|
VNP608, VEM608, VNP708, VEM708
|
1'', 1-1/2''
|
NBR
|
|
DB112/G
|
VNP212, VEM212, VNP312, VEM312,
VNP412, VEM412
|
1-1/2''
|
NBR
|
|
DB114/C
|
VNP214, VEM214, VNP314, VEM314, VNP414, VEM414, VNP614, VEM614, VNP714, VEM714 |
1-1/2''
|
NBR
|
|
DB116/C
|
VNP216, VEM216, VNP416, VEM416, VNP616, VEM616, VNP716, VEM716 |
2''
|
NBR
|
|
DB120/C
|
VNP220, VEM220, VNP420, VEM420, VNP424, VEM424, VNP620, VEM620, VNP720, VEM720 |
2-1/2'', 3''
|
NBR
|
|
Tips: EPDM, FKM all available.
|
|||
Dimension of DB116 Diaphragm:
Video of DB116 Diaphragm:
Pictures of Pulse Valve Membrane Production:
