| 원래 장소: | 중국 |
| 브랜드 이름: | BRANDO |
| 인증: | None |
| 모델 번호: | 2W500-50K |
| 최소 주문 수량: | 1 PC |
|---|---|
| 가격: | 협상 가능 |
| 포장 세부 사항: | 내부 상자, 판지, 팔레트 |
| 배달 시간: | 협상 |
| 지불 조건: | T/T,웨스턴 유니온,머니그램 |
| 공급 능력: | 달 당 100000 PC |
| 포트 크기: | 2'' | 오리피스 크기: | 50mm |
|---|---|---|---|
| 행동: | 직접 리프팅 다이어프램 | 메디아: | 물 공기 가스 |
| 본체 재질: | 놋쇠 | 다이어프램 재질: | NBR, FKM, EPDM |
| 압력 범위: | 0 내지 1 MPa | 전압: | 12VDC, 24VDC, 24VAC, 110VAC, 220VAC |
| 기능: | 2 방식 비접점 | ||
| 강조하다: | 2'' Normally Open Brass Solenoid Valve,Normally Open Brass Valve 2 inch,2'' Normally Open Solenoid Valve |
||
2 Inch Normally Open Brass Electric Solenoid Valve 24V 110V 220V
2W-K series are 2 way normally open solenoid valves with port sizes from 3/8'' to 2''. The standard valve body material is brass, and the standard diaphragm material is NBR, EPDM or FKM can be customized according to your requirements to control different media like water, air, gas and liquids, etc. The working pressure range is from 0 to 8 bar, and there are various voltages for you to choose, 12VDC, 24VDC, 24VAC, 110VAC or 220VAC. If you have demands, pls contact us!
Technical Data:
|
Model No
|
2W160-10K
|
2W160-15K
|
2W200-20K
|
2W250-25K
|
2W350-35K
|
2W400-40K
|
2W500-50K
|
|
Orifice Size
|
16mm
|
16mm
|
20mm
|
25mm
|
35mm
|
40mm
|
50mm
|
|
Port Size
|
3/8''
|
1/2''
|
3/4''
|
1''
|
1-1/4''
|
1-1/2''
|
2''
|
|
Body Material
|
Brass
|
||||||
|
Diaprhagm Material
|
NBR, EPDM, FKM
|
||||||
|
Working Medium
|
Water, Air, Gas, Liquid, etc
|
||||||
|
Operation
|
Direct Lifting Diaphragm
|
||||||
|
Function
|
2 Way Normally Open
|
||||||
|
Fluid Viscosity
|
20 CST below
|
||||||
|
Working Pressure
|
0 to 8 bar
|
||||||
|
Working Temperature
|
NBR: -5 to +80℃
EPDM: -5 to +120℃ FKM: -10 to +150℃ |
||||||
|
Voltage
|
12VDC, 24VDC, 24VAC, 110VAC, 220VAC
|
||||||
Main Dimension:
|
Model No
|
Port
|
A
|
B
|
C
|
D
|
|
2W160-10K
|
3/8''
|
63
|
56
|
181
|
118
|
|
2W160-15K
|
1/2''
|
63
|
56
|
181
|
118
|
|
2W200-20K
|
3/4''
|
66
|
56
|
122
|
123
|
|
2W250-25K
|
1''
|
90
|
76
|
130
|
147
|
|
2W350-35K
|
1-1/4''
|
99
|
76
|
134
|
160
|
|
2W400-40K
|
1-1/2''
|
115
|
93
|
160
|
165
|
|
2W500-50K
|
2''
|
133
|
93
|
170
|
176
|
