| 원래 장소: | 중국 |
| 브랜드 이름: | BRANDO |
| 인증: | None |
| 모델 번호: | PU225A-06 |
| 최소 주문 수량: | 1 PC |
|---|---|
| 가격: | 협상 가능 |
| 포장 세부 사항: | 내부 상자, 판지, 팔레트 |
| 배달 시간: | 협상 |
| 지불 조건: | T/T,웨스턴 유니온,머니그램 |
| 공급 능력: | 달 당 100000 PC |
| 포트 크기: | 3/4'' | 오리피스 크기: | 25mm |
|---|---|---|---|
| 작동 압력 범위: | 0.05 ~ 1 MPa | 기능: | 2가지 방식은 정상적으로 마감되었습니다 |
| 본체 재질: | 놋쇠 | 다이어프램 재질: | NBR, FKM, EPDM |
| 전압: | 12VDC, 24VDC, 24VAC, 110VAC, 220VAC | 작업: | 진동판 파일럿은 작동했습니다 |
| 강조하다: | SHAKO Solenoid valve PU225A-06,Shako 2/2 Way Solenoid Valve PU225A Series 3/4'',SHAKO PU225A-06 AC220V |
||
SHAKO Type Brass valve PU225A-06 2/2 Normally Closed Solenoid Valve PU225A Series
This is PU225A-06 solenoid valve, 3/4'' port, 25mm orifice, 0.5 to 10 bar, diaphragm pilot operated, 2 way normally closed, brass body, NBR standard diaphragm, can be customized as EPDM or FKM diaphragm to suit different working mediums, various voltages for your choice, such as 12VDC, 24VDC, 24VAC, 110VAC and 220VAC, etc. It is used for a wide arrange of industrial applications to control fluids.
Product Features:
1. Working Medium: Water, Air, Gas, Liquid, Light Oil, etc
2. Working Pressure: 0.5 to 10 bar
3. Medium Temperature: NBR (-5 to +80ºC), EPDM (-5 to +120ºC), FKM (-10 to +150ºC)
4. Port Size: 3/8'', 1/2'', 3/4'', 1'', 1-1/4'', 1-1/2'', 2''
5. Orifice Size: 13mm, 25mm, 38mm, 50mm
6. Body Material: Brass
7. Diaphragm Material: NBR, EPDM, FKM
8. Operation: Diaphragm Pilot Operated
9. Function: 2 Way Normally Closed
10. Voltage: 12VDC, 24VDC, 24VAC, 110VAC, 220VAC (50/60Hz)
Technical Data:
|
Model No
|
PU225A-03
|
PU225A-04
|
PU225A-06
|
PU225A-08
|
PU225A-12
|
PU225A-14
|
PU225A-20
|
|
Orifice Size
|
13mm
|
25mm
|
38mm
|
50mm
|
|||
|
Port Size
|
3/8''
|
1/2''
|
3/4''
|
1''
|
1-1/4''
|
1-1/2''
|
2''
|
|
Medium
|
Water, Air, Light oil, Gas, Liquid, etc
|
||||||
|
Operation
|
Diaphragm Pilot Operated
|
||||||
|
Function
|
2 Way Normally Closed
|
||||||
|
Body Material
|
Brass
|
||||||
|
Diaphragm Material
|
NBR (Standard), EPDM, FKM (Optional)
|
||||||
|
Working Pressure
|
0.5 to 10 bar
|
||||||
|
Working Temperature
|
NBR: -5 to +80ºC
EPDM: -5 to +120ºC FKM: -10 to +150ºC |
||||||
|
Voltage
|
12VDC, 24VDC, 24VAC, 110VAC, 220VAC
|
||||||
Main Dimension:
|
Model Number
|
Port
|
A
|
B
|
C
|
|
PU225A-03
|
3/8''
|
67.5
|
106
|
48
|
|
PU225A-04
|
1/2''
|
67.5
|
106
|
48
|
|
PU225A-06
|
3/4''
|
75
|
112
|
58
|
|
PU225A-08
|
1''
|
96
|
124.5
|
70
|
|
PU225A-12
|
1-1/4''
|
130
|
139
|
97
|
|
PU225A-14
|
1-1/2''
|
130
|
139
|
97
|
|
PU225A-20
|
2''
|
161
|
160.5
|
112
|
